Synchrotron SAXS
data from solutions of
Atg1-Atg13-Atg17-Atg31-Atg29 Minipentamer Complex
in
20 mM Tris, 200 mM NaCl, pH 8
were collected
on the
12.3.1 (SIBYLS) beam line
at the Advanced Light Source (ALS) storage ring
(Berkeley, CA, USA)
using a Pilatus3 X 2M detector
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
Solute concentrations ranging between 0.7 and 2.6 mg/ml were measured
at 22°C.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
Wavelength = UNKNOWN. Sample detector distance = UNKNOWN. Number of frames = UNKNOWN
s, nm-1
