Structure and catalytic mechanism of the evolutionarily unique bacterial chalcone isomerase.

Thomsen M, Tuukkanen A, Dickerhoff J, Palm GJ, Kratzat H, Svergun DI, Weisz K, Bornscheuer UT, Hinrichs W, Acta Crystallogr D Biol Crystallogr 71(Pt 4):907-17 (2015) Europe PMC

SASDAL6 – Wild-type chalcone isomerase, ligand-free

Bacterial chalcone isomerase
MWI(0) 190 kDa
MWexpected 194 kDa
VPorod 320 nm3
log I(s) 3.23×104 3.23×103 3.23×102 3.23×101
Bacterial chalcone isomerase small angle scattering data  s, nm-1
ln I(s)
Bacterial chalcone isomerase Guinier plot ln 3.23×104 Rg: 4.0 nm 0 (4.0 nm)-2 s2
(sRg)2I(s)/I(0)
Bacterial chalcone isomerase Kratky plot 1.104 0 √3 sRg
p(r)
Bacterial chalcone isomerase pair distance distribution function Rg: 3.7 nm 0 Dmax: 13 nm

Data validation

There are no models related to this curve.

Synchrotron SAXS data from solutions of Wild-type chalcone isomerase, ligand-free in 50 mM sodium phosphate, pH 6.8 were collected on the EMBL P12 beam line at the PETRA III storage ring (DESY; Hamburg, Germany) using a Pilatus 2M detector at a sample-detector distance of 3.1 m and at a wavelength of λ = 0.124 nm (I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle). Solute concentrations ranging between 1.4 and 15.3 mg/ml were measured at 10°C. 20 successive 0.050 second frames were collected. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted. The low angle data collected at lower concentrations were extrapolated to infinite dilution and merged with the higher concentration data to yield the final composite scattering curve.

Bacterial chalcone isomerase (CHI)
Mol. type   Protein
Organism   Eubacterium ramulus
Olig. state   Hexamer
Mon. MW   32.4 kDa

UniProt   V9P0A9
Sequence   FASTA
