MWexperimental | 47 | kDa |
MWexpected | 42 | kDa |
VPorod | 80 | nm3 |
log I(s)
4.24×103
4.24×102
4.24×101
4.24×100
|
s, nm-1
|
|
|
|
|
|
|
Synchrotron SAXS
data from solutions of
DEAD box helicase DDX3
in
50 mM HEPES 150 mM NaCl, pH 7.5
were collected
on the
EMBL P12 beam line
at the PETRA III storage ring
(DESY; Hamburg, Germany)
using a Pilatus 2M detector
at a sample-detector distance of 3.1 m and
at a wavelength of λ = 0.12 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
One solute concentration of 2.00 mg/ml was measured
at 10°C.
20 successive
0.050 second frames were collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
|
|
