| MWexperimental | 271 | kDa |
| MWexpected | 260 | kDa |
| VPorod | 1100 | nm3 |
|
log I(s)
1.02×105
1.02×104
1.02×103
1.02×102
|
s, nm-1
|
[Fe-S] cluster biogenesis and unusual assembly of the ISC scaffold complex in Plasmodium falciparum mitochondrion
Ravishankar Ramachandran.SASDJN7 – Cysteine desulfurase, Iron-sulfur cluster assembly protein (IscS_IscU) complex
Iron-sulfur cluster assembly proteinCysteine desulfurase, putative
|
|
|
Fits and models
|
|
|
SAXS data from solutions of the IscS_IscU complex in 50 mM Tris-Cl, 300 mM NaCl, 5% Glycerol, pH 7.5 were collected using an Anton Paar SAXSpace instrument at the CSIR-Central Drug Research Institute (Lucknow, India) equipped with a Dectris Mythen 2R1K detector at a sample-detector distance of 0.3 m and at a wavelength of λ = 0.154 nm (I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle). One solute concentration of 3.00 mg/ml was measured at 9.8°C. Two successive 30 second frames were collected. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
CAUTION: The error on Rg is over 5 nm. CAUTION! Errors are severely over estimated! CAUTION! Porod volume is inconsistent with the quoted MW of 270 kDa. |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||
