MWexperimental | 72 | kDa |
MWexpected | 71 | kDa |
VPorod | 111 | nm3 |
log I(s)
1.13×106
1.13×105
1.13×104
1.13×103
|
s, nm-1
|
|
|
|
Rg, nm
|
|
|
Synchrotron SAXS
data from solutions of
Human Heat Shock Cognate 71 kDa Protein (HSPA8 / Hsc70)
in
25 mM Tris HCl, 50 mM NaCl, 5 mM Sodium Phosphate, 5 mM KCl, pH 7.5
were collected
on the
SAXS1 Beamline beam line
at the Brazilian Synchrotron Light Laboratory storage ring
(Campinas, Brazil)
using a Pilatus 300K detector
at a sample-detector distance of 1 m and
at a wavelength of λ = 0.1488 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
One solute concentration of 1.00 mg/ml was measured
at 27°C.
10 successive
10 second frames were collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
Storage temperature = UNKNOWN |
|
