Goradia N,
Werner S,
Mullapudi E,
Greimeier S,
Bergmann L,
Lang A,
Mertens H,
Węglarz A,
Sander S,
Chojnowski G,
Wikman H,
Ohlenschläger O,
von Amsberg G,
Pantel K,
Wilmanns M,
Nat Commun
15(1):5241
(2024)
Europe PMC
SASDQ96 – C-terminal-binding protein 1 (CtBP1) bound to Retinoic acid-induced protein 2 (RAI2: 303-362) M2 mutant L345A, S346A
Synchrotron SAXS
data from solutions of
C-terminal-binding protein 1 (CtBP1) bound to Retinoic acid-induced protein 2 (RAI2: 303-362) M2 mutant L345A, S346A
in
50 mM HEPES, 150 mM NaCl, 1 mM TCEP, 5% v/v glycerol, pH 7.2
were collected
on the
EMBL P12 beam line
at the PETRA III storage ring
(DESY; Hamburg, Germany)
using a Pilatus 6M detector
at a sample-detector distance of 3 m and
at a wavelength of λ = 0.124 nm
(I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle).
One solute concentration of 6.00 mg/ml was measured
at 20°C.
40 successive
0.200 second frames were collected.
The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
s, nm-1
