Synchrotron SAXS data from solutions of outer membrane protein MIP (LpMIP) with bound inhibitor JK095 in 20 mM Tris-HCl, 150 mM NaCl, 10 mM DTT, pH 7.5 were collected on the EMBL P12 beam line at PETRA III (DESY; Hamburg, Germany) using a Pilatus 6M detector at a sample-detector distance of 3 m and at a wavelength of λ = 0.124 nm (I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle). In-line size-exclusion chromatography (SEC) SAS was employed. The SEC parameters were as follows: A 45.00 μl sample at 10 mg/ml was injected at a 0.30 ml/min flow rate onto a GE Superdex 200 Increase 5/150 column at 20°C. 2400 successive 0.250 second frames were collected. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
The PubChem entry for the Inhibitor JK095 can be found under:
https://pubchem.ncbi.nlm.nih.gov/compound/118257702
|
|
