Synchrotron SAXS data from solutions of mRNA capping enzyme small subunit in 20 mM Tris, 150 mM NaCl, pH 8 were collected on the BL19U2 beam line at the Shanghai Synchrotron Radiation Facility (SSRF; Shanghai, China) using a Pilatus 1M detector at a sample-detector distance of 1 m and at a wavelength of λ = 0.1033 nm (I(s) vs s, where s = 4πsinθ/λ, and 2θ is the scattering angle). One solute concentration of 1.00 mg/ml was measured at 25°C. 10 successive 6 second frames were collected. The data were normalized to the intensity of the transmitted beam and radially averaged; the scattering of the solvent-blank was subtracted.
Possibly aggregated. The dummy atom models displayed in this entry show: Top - the minimised volume and bead-occupancy 'averaged' shape obtained from the spatial alignment of a ten-member individual model cohort (DAMFILT) and; Bottom - an example of an individual model, with the corresponding individual-model fit to the data (displayed to the left). The ten-member model cohort is available for download in the full entry zip archive.
|
|
s, nm-1
